Create an SAP HANA Graph Workspace
Details

Create an SAP HANA Graph Workspace

sygyzmundovych
sygyzmundovych
January 14, 2021
Created by
sygyzmundovych
December 19, 2018
Beginner
10 min.
SAP HANA, Tutorial, SAP HANA Cloud, SAP HANA, express edition, SQL, Beginner
Get an overview of what SAP HANA Graph is, load some sample data, and create your first graph workspace based on that data.

You will learn

  • What SAP HANA Graph is
  • How to create graph workspace using sample data
QR code

Prerequisites

Step 1: SAP HANA Graph

SAP HANA Graph is an integral part of SAP HANA core functionality. It expands the SAP HANA with native support for graph processing and allows you to execute typical graph operations on the data stored in an SAP HANA system.

Graphs are a powerful abstraction that can be used to model different kinds of networks and linked data coming from many industries, such as logistics and transportation, utility networks, knowledge representation, text processing, and so on.

In SAP HANA, a graph is a set of vertices and a set of edges. Each edge connects two vertices; one vertex is denoted as the source and the other as the target. Edges are always directed and there can be two or more edges connecting the same two vertices. Vertices and edges can have an arbitrary number of attributes. A vertex attribute consists of a name that is associated with a data type and a value. Edge attributes consist of the same information.

Graph

For more please refer to online documentation for SAP HANA Cloud used in these exercises.

Done
Log on to answer question
Step 2: Exercise data

You will have a model and data representing a part of the real life ski resort Pinzolo/Madonna di Campiglio in Italy. The full-size picture of the map is available in the file and the small-scale version can be found below.

map

Every station got an id number (in red circle) and will become a vertex of our graph. They have additional attributes:

  • ticket_office = 'TRUE' (string, not boolean), is where you buy a ticket and start the day. These are stations 1, 4, 15.
  • restaurant = 'TRUE' is a place to have a break for a delicious Italian coffee, or to recharge with a few slices of pizza. These are stations 2, 3, 5.

Stations are connected by either lifts (to go up) or runs (to ski down). These connections will be edges in the graph with a few attributes:

  • ‘lift’ or ‘run’ will be their mode attribute,
  • start and end will be ids of connected stations,
  • each of them will have attribute length, measured in meters,
  • additionally, runs will have ‘blue’, ‘red’, or ‘black’ values in the attribute difficulty,
  • attribute status is either ‘open’ or ‘close’, reflecting if particular lift or run can be used. By default, all connections will be open.
Done
Log on to answer question
Step 3: Create tables
View Full Instructions

Open SAP HANA Database Explorer’s SQL Editor and connect to your database.

The assumption in these exercises is that you are using a schema SKIING, but you can change it to any other schema of your choice.

Copy the following code into your SQL Editor.

--DROP SCHEMA "SKIING" CASCADE;
CREATE SCHEMA "SKIING";
SET SCHEMA "SKIING";

CREATE TABLE "NODES"(
	"node_id" INTEGER NOT NULL,
	"name" NVARCHAR(16),
	"ticket_office" NVARCHAR(4),
	"restaurant" NVARCHAR(4),
	PRIMARY KEY (
		"node_id"
	)
);

CREATE TABLE "EDGES"(
	"edge_id" INTEGER NOT NULL,
	"length" INTEGER,
	"difficulty" NVARCHAR(16),
	"start" INTEGER NOT NULL,
	"end" INTEGER NOT NULL,
	"mode" NVARCHAR(8),
	"status" NVARCHAR(8),
	PRIMARY KEY (
		"edge_id"
	)
);

ALTER TABLE "EDGES" ADD FOREIGN KEY ("start") REFERENCES "NODES" ("node_id") ON UPDATE CASCADE ON DELETE CASCADE ENFORCED VALIDATED
;
ALTER TABLE "EDGES" ADD FOREIGN KEY ( "end" ) REFERENCES "NODES" ("node_id") ON UPDATE CASCADE ON DELETE CASCADE ENFORCED VALIDATED
;

Execute all statements.

You should see two tables created in your schema.

Created tables
Done
Log on to answer question
Step 4: Review tables

Open review definitions of both tables.

Review tables
Done
Log on to answer question
Step 5: Insert data
View Full Instructions

Copy following code into your SQL Editor and execute it.

SET SCHEMA "SKIING";

--Populate NODES
INSERT INTO "NODES" VALUES (1, 'Pinzolo', 'TRUE', '') ;
INSERT INTO "NODES" VALUES (2, 'Pra Rodont', '', 'TRUE') ;
INSERT INTO "NODES" VALUES (3, 'Dos Del Sabion', '', 'TRUE') ;
INSERT INTO "NODES" VALUES (4, 'Tulot', 'TRUE', '') ;
INSERT INTO "NODES" VALUES (5, 'Malga Ciocia', '', 'TRUE') ;
INSERT INTO "NODES" VALUES (6, 'Malga Ciocia Up', '', '') ;
INSERT INTO "NODES" VALUES (7, 'Zapel', '', '') ;
INSERT INTO "NODES" VALUES (8, 'Zapel Down', '', '') ;
INSERT INTO "NODES" VALUES (9, 'Grual', '', '') ;
INSERT INTO "NODES" VALUES (10, 'Mte Grual', '', '') ;
INSERT INTO "NODES" VALUES (11, 'Malga Grual', '', '') ;
INSERT INTO "NODES" VALUES (12, 'Fossadei', '', '') ;
INSERT INTO "NODES" VALUES (13, 'Puza Daifo', '', '') ;
INSERT INTO "NODES" VALUES (14, 'Plaza', '', '') ;
INSERT INTO "NODES" VALUES (15, 'Colarin', 'TRUE', '') ;

--Populate EDGES
INSERT INTO "EDGES" VALUES (61, 1755, '', 1, 2, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (62, 1718, '', 2, 3, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (60, 2453, '', 4, 5, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (63, 123, '', 12, 2, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (64, 1050, '', 12, 6, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (65, 1041, '', 8, 7, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (66, 365, '', 9, 7, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (67, 1312, '', 11, 3, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (68, 360, '', 9, 10, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (69, 1365, '', 13, 10, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (70, 1223, '', 14, 13, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (71, 1151, '', 15, 14, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (100, 2600, 'black', 5, 4, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (101, 3100, 'red', 3, 2, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (102, 2500, 'black', 3, 2, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (103, 2000, 'black', 3, 9, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (104, 2100, 'red', 3, 9, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (105, 1200, 'red', 9, 11, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (106, 2000, 'red', 7, 11, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (107, 1800, 'red', 7, 8, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (108, 700, 'red', 7, 5, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (1108, 1000, 'red', 5, 8, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (109, 1900, 'blue', 6, 2, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (110, 200, 'blue', 2, 12, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (111, 700, 'blue', 10, 9, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (112, 1500, 'red', 10, 13, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (113, 700, 'black', 3, 5, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (114, 600, 'blue', 6, 2, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (116, 2100, 'red', 3, 9, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (117, 2300, 'black', 12, 4, 'run', 'open') ;
INSERT INTO "EDGES" VALUES (118, 200, 'blue', 6, 5, 'run', 'open') ;
Done
Log on to answer question
Step 6: Preview data

Switch to the tab with one of table definitions, and click on Open Data. Then repeat it for the second table too.

Data preview

There should be 15 rows in the table NODES and 31 rows in the table EDGES.

Done
Log on to answer question
Step 7: Create a graph workspace
View Full Instructions

Copy following code into your SQL Editor and execute it.

SET SCHEMA "SKIING";

CREATE GRAPH WORKSPACE "SKIING"
  EDGE TABLE "EDGES"
    SOURCE COLUMN "start"
    TARGET COLUMN "end"
    KEY COLUMN "edge_id"
  VERTEX TABLE "NODES"
    KEY COLUMN "node_id"
;
Done
Log on to answer question
Step 8: Check the workspace artifact

Find just created SKIING workspace in the Graph Workspaces folder of your schema.

Click on it to open its definition.

Graph workspace
What was the name of the table used as the vertex table in the graph workspace?
×
Step 9: Open Graph Viewer

Right click on SKIING graph workspace and pick View Graph.

The graph viewer will open and load the initial view of graph.

Note, that the rendering of graph’s nodes and edges is different every time

Open Graph Viewer
Done
Log on to answer question
Step 10: Customize a view of the graph

Use Preferences to customize the view of the graph.

Add edge labels

You should see labels of edges now.

Done
Log on to answer question
Step 11: Add more data
View Full Instructions

In reality these lifts starting from the ticket offices can be used as well to go down. So, let’s add additional edges.

Add four new records to EDGES table by executing following INSERT statements in the SQL Console.

--Add lifts down to boarding stations
INSERT INTO "EDGES" VALUES (1061, 1755, '', 2, 1, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (1060, 2453, '', 5, 4, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (1070, 1223, '', 13, 14, 'lift', 'open') ;
INSERT INTO "EDGES" VALUES (1071, 1151, '', 14, 15, 'lift', 'open') ;
Done
Log on to answer question
Step 12: Reset preview of the graph

Go back to Graph Viewer and click on Reset Graph.

Note, that the rendering of graph’s nodes and edges is different every time

Open Graph Viewer

You should see lift connections in both directions now.

Done
Log on to answer question
