xP&A HXM Workforce Planning - Add a new Plan Level

This tutorial provides information about how to add a new Plan Level.
You will learn
  • The meaning of the term Plan Level in the context of the HXM Operational Workforce Planning Content Package for SAP Analytics Cloud
  • Which steps are required in order to add a new Plan Level
  • This includes…
    -modifying dimensions in the data model
    -adjusting all affected Data Actions
    -maintaining cost parameters for the new Plan Level
Rudolf LindtOctober 12, 2022
Created by
RudolfLindt93
October 12, 2022
Contributors
RudolfLindt93

Prerequisites

  • Step 1

    In the scope of the Human Resources - HXM Operational Workforce Planning Content Package for SAP Analytics Cloud, the term Plan Level describes the high level point of view which is used by the planner for the planning activities.

    Per default, the content package comes with five pre-defined Plan Levels.

    • The pre-defined Plan Level PL1 enables the planner to perform planning activities on a Company Code + Business Unit aggregation level for instance.
    • The pre-defined Plan Level PL2 enables the planner to perform planning activities on a Company Code + Business Unit + Division aggregation level.
    • The pre-defined Plan Levels PL3 and PL4 enable the planner to perform planning activities on a Company Code + Cost Center aggregation level. While Plan Level PL3 and Plan Level PL4 provide the same point of view, PL3 is used for the aggregated planning scenario while PL4 is used for the detailed planning scenario.
    • The pre-defined Plan Level PL5 enables the planner to perform planning activities on a Company Code + Business Unit + Job Family aggregation level.

    If you wish to define a different point of view, you can do so by adding a new Plan Level member to the plan level dimension.

    In this specific tutorial, you will learn how to create a new Plan Level which enables planners to perform planning activities on a Company Code + Job Family level.

  • Step 2

    In the first step, it is necessary to add a new member to the Plan_Level dimension.

    1. In the SAP Analytics Cloud Menu, navigate to the Files section.

    2. Search for the SAP__HR_BPL_IM_WORKFORCE data model and open it.

      Data_Model
    3. Click on the dimension Plan_Level.

      Select_Plan_Level_Dim
    4. Add a new member to the Plan Level dimension.

      In this example, the Plan Level PL6 representing a Company Code + Job Family aggregation level is added.

      • Make sure to active grid mode (you can find the button on the top right corner)
      • Add the according attributes to the new Element-ID as shown in the below table or screenshot
      Column Value Comment
      Member ID PL6 Mandatory ID field
      Description CompanyCode, JobFamily Description of the new Plan Level member
      Planning Direction Aggregated Mandatory field. Shows whether this Plan Level is applied to the aggregated or detailed planning scenario¹
      Plan Dimensions jobFunction Mandatory field. Ensure that the spelling of the dimension matches with the spelling maintained in the whitelist²
      Add_New_Member

      ¹Allowed entries for the Planning Direction column are only the values Aggregated or Detailed. Other keywords will not be recognized by the planning applications.

      ²Allowed entries for the Plan Dimensions column are only values which are maintained in the dimension whitelist.

      • This whitelist can be found in every single planning application of this content package and also must be maintained in each application of this content package in case of changes.

      • In order to check the whitelist, open any planning application in edit mode and enter the onInitialization script.

        Whitelist
      • The dictionary cfg_dimensionMapping contains a mapping between the technical name of all dimensions of the data model and its written name (maintained in camel case naming convention).

      • The column Plan Dimensions must be populated with one of these dimensions under consideration of the spelling (except for the companyCode dimension, as it is part of each Plan Level per default).

      • In case your Plan Level contains more than one additional dimension apart from the Company Code dimension, you may enter multiple dimensions. Make sure to separate them with a comma without any spaces as it is the case for Plan Level PL1 or PL5.

    5. Save your changes.

  • Step 3

    In the next step, you will set the new Plan Level PL6 as the default aggregation level for the Aggregated_Plan version.

    In order to do so, the properties of the Version dimension need to be modified.

    By doing this, your planning applications will automatically initialize all planning grids according to the definition of your new Plan Level. That means that all planning grids will initialize with a structure which enable you to make your entries on a Company Code + Job Family level.

    1. Navigate back to the Model Structure workspace by hitting the back button on the top left corner and click on the dimension Version.

    2. Change the value of the attribute Plan Level for the public.Aggregated_Plan version to PL6 in order for the planning applications to initialize accordingly.

      Modify_Version_Dim
    3. Save your changes.

  • Step 4

    In the next step, all affected Data Actions must be adjusted in order to make calculations for the new Plan Level PL6work.

    1. Navigate to the Data Action menu and open the Data Action SAP__HR_BPL_IM_INITIALIZE_PLAN_WITH_AGGREGATION.

      Data_Action_Menu
    2. Click on the second Data Action step Seeding Internal and complement the code with the following statement by adding these lines at the very end of the Data Action step:

      ELSEIF @PlanLevelNumeric = 6 THEN

      //Aggregate all data from the specified ReferencePeriod of the Actual Version to CompanyCode/JobFunction (PL6) level and copy these values to the dates of the planning horizon (specified in Memberset)
      //Hint: Specify all dimensions except for CompanyCode/JobFunction
      DATA([d/Plan_Level] = "PL6",
      	 [d/SAP_HR_ISCONTINGENT] = "false",
      	 [d/Audit] = "INIT",
      	 [d/SAP_HR_USER_EMPLOYEE] = "#",
      	 [d/SAP_HR_POSITION] = "#",
      // [d/SAP_ALL_COMPANY_CODE] = "#",
         [d/SAP_HR_BUSINESSUNIT] = "#",
      	 [d/SAP_HR_DIVISION] = "#",
      	 [d/t.S:SAP_ALL_COSTCENTER] = "#",
         [d/t.S:SAP_HR_USER_PAYGRADE] = "#",
      	 [d/t.S:SAP_HR_USER_JOBCLASSIFICATION] = "#",
      	 [d/SAP_HR_DEPARTMENT] = "#",
      	 [d/SAP_HR_USER_LOCATION] = "#",
      	 [d/SAP_HR_USER_EVENT] = "#",
      	 [d/SAP_HR_USER_EMPLOYMENTTYPE] = "#",
      	 [d/SAP_HR_USER_JOBLEVEL] = "#",
      	 [d/SAP_HR_USER_CONTRACTTYPE] = "#",
      	 [d/SAP_HR_GEOZONE] = "#",
      	 [d/SAP_HR_USER_PAYRANGE] = "#",
      // [d/SAP_HR_JOBFUNCTION] = "#",
      	 [d/SAP_FI_IFP_GLACCOUNT] = "#"
      	 ) = RESULTLOOKUP([d/Version] = "public.Actual", [d/Date] =  [d/Version].[p/ReferencePeriod])

      ENDIF


      Your result should look like this:

      Data_Action_Seeding

      EXPLANATION:

      • In order to make cost calculations for Plan Level PL6 work, add a new ELSEIF statement as shown in the image above.
      • For simplification reasons, you can copy one code block from any other Plan Level and paste it at the bottom of the Data Action step.
      • If you do this, make sure to change the commented header accordingly so the description matches to the new code.
      • Ensure that you adjust the ELSEIF condition as well and check for PlanLevelNumeric = 6. The number 6 represents the Plan Level PL6. Accordingly, the number 1 would represent the Plan Level PL1, number 2 the Plan Level PL2 etc.
      • In this example, the dimensions [d/SAP_ALL_COMPANY_CODE] and [d/SAP_HR_JOBFUNCTION] must be excluded from the code as they are part of the definition of Plan Level PL6. You can exclude dimensions by putting them into a comment as shown in the image.
      • In order for the calculation to work correctly, you must always exclude those dimensions (i.e by putting them into a comment) that are part of your Plan Level definition, which in the case of Plan Level PL6 are [d/SAP_ALL_COMPANY_CODE] and [d/SAP_HR_JOBFUNCTION].
    3. Repeat the same activity for the third Data Action step Seeding External.

      ELSEIF @PlanLevelNumeric = 6 THEN

      //Aggregate all data from the specified ReferencePeriod of the Actual Version to CompanyCode/JobFunction (PL6) level and copy these values to the dates of the planning horizon (specified in Memberset)
      //Hint: Specify all dimensions except for CompanyCode/JobFunction
      DATA([d/Plan_Level] = "PL6",
        [d/SAP_HR_ISCONTINGENT] = "true",
        [d/Audit] = "INIT",
        [d/SAP_HR_USER_EMPLOYEE] = "#",
        [d/SAP_HR_POSITION] = "#",
      //[d/SAP_ALL_COMPANY_CODE] = "#",
        [d/SAP_HR_BUSINESSUNIT] = "#",
        [d/SAP_HR_DIVISION] = "#",
        [d/t.S:SAP_ALL_COSTCENTER] = "#",
        [d/t.S:SAP_HR_USER_PAYGRADE] = "#",
        [d/t.S:SAP_HR_USER_JOBCLASSIFICATION] = "#",
        [d/SAP_HR_DEPARTMENT] = "#",
      //[d/SAP_HR_USER_LOCATION] = "#",
        [d/SAP_HR_USER_EVENT] = "#",
        [d/SAP_HR_USER_EMPLOYMENTTYPE] = "#",
        [d/SAP_HR_USER_JOBLEVEL] = "#",
        [d/SAP_HR_USER_CONTRACTTYPE] = "#",
        [d/SAP_HR_GEOZONE] = "#",
        [d/SAP_HR_USER_PAYRANGE] = "#",
      //[d/SAP_HR_JOBFUNCTION] = "#",
        [d/SAP_FI_IFP_GLACCOUNT] = "#"
      ) = RESULTLOOKUP([d/Version] = "public.Actual", [d/Date] =  [d/Version].[p/ReferencePeriod])

      ENDIF

      Data_Action_Seeding
    4. Save your Data Action.

  • Step 5

    Lastly you need to maintain Central Assumptions for the Plan Level PL6.

    Here you can access the tutorial xP&A HXM Workforce Planning - Create and Upload Central Assumptions in order to learn how to upload and maintain Central Assumptions.

    Congratulations! You have now added a new planning point of view to your workforce planning solution by extending the Plan Level dimension.
