Enable Certificate-Based Authentication
Details

Enable Certificate-Based Authentication

November 28, 2021
Created by
April 14, 2021
Create a branded MDK client that can on-board using certificates for authentication.

You will learn

  • How to define your Mobile Services app to support certificate authentication
  • How to configure the MDK client
  • How to build a branded client
QR code

Prerequisites


Step 1: Configure a new MDK application in Mobile Services cockpit
  1. Navigate to SAP Mobile Services cockpit.

  2. On the home screen, select Create new app.

    MDK
  3. In Basic Info step, provide the required information and click Next.

    Field Value
    ID com.sap.mdk.certs
    Name SAP MDK cert auth App
    MDK

    If you are configuring this app in a trial account, make sure to select License Type as lite.

  4. In Assign Features step, choose Mobile Development Kit Application from the dropdown, and click Finish.

    MDK

    If you see a Confirm Finish window, click OK.

Log on to answer question
Step 2: Modify default OAuth security settings

When you configure an MDK app in Mobile Service cockpit, OAuth security is assigned to the app by default.

To enable certificate based authentication, you need to modify Redirect URL in Security configuration.

  1. Click Security.

    MDK
  2. Click pencil icon to make changes to default configuration.

    MDK
  3. Replace the Redirect URL with mdkclient://oauth2redirect parameter, and click OK to save the changes. This Redirect URL needs to be added in the AllowedDomains property while building your branded client (step 3.5).

    MDK

    mdkclient is an URL scheme for your branded MDK client, you will use this value in step 3.3.

    oauth2redirect is just a random path. It could be any value.

Log on to answer question
Step 3: Create your .mdkproject folder

Make sure you are choosing the right development platform tab above.

Make sure that you have already completed steps 1 & 2 from this tutorial.

  1. In the MDKClient_SDK folder, you will find the template.mdkproject folder.

    MDK

    It is recommended that you copy this folder to another location so that you can to use it for future builds. Copy and paste it anywhere, and then rename the template to MDKCertApp.mdkproject.

    MDK
  2. Next, you will need to update the BrandedSettings.json and MDKProject.json files as needed for your client. Go into the MDKCertApp.mdkproject folder.

    MDK
  3. Open the MDKProject.json file and update it as needed. This file has some build-time configurations such as the application name, version and bundle ID.

    MDK

    AppName: Provide a name for example: MDKCertApp. It is the name of the application on the home screen of the device and it is also be the name of the folder where the client is created.

    BundleID: It should be a unique identifier for your application. This controls if the client can be installed side by side with other applications on the device. Two applications with the same Bundle ID cannot be installed at the same time on a device. For iOS this is the Identifier (AppID) that is registered in Apple Developer account since that determines if the application can be installed alongside other applications. If the XCode project is set up to use Automatically manage signing then when building, XCode will automatically generate a signing profile for the specified bundle id. Without matching them, trying to run the custom client in iOS device will result in failure. In Android, it is known as application ID.

    URLScheme: Allows you to specify a custom URL scheme which opens the client. This value is provided in step 2 for Redirect URL.
    If the URL includes connection settings as URL parameters, these settings will override the ones used by the client. The default is mdkclient. This value needs to match the value provided in step 2 for the Redirect URL. This value also needs to be unique across applications on your device. If the value is not unique the wrong application may be referenced when redirecting.

  4. Open the BrandedSettings.json file and update the ConnectionSettings with the values for your MDK application in Mobile Services. You also need to add the "AllowCerts":true property into the ConnectionSettings block.

    MDK

    AllowCerts property allows MDK client to use the certificate. You can find more information about this property in help documentation. To access the certificate on the device during on-boarding if requested by the Identity provider (IdP).

    To find the correct URLs for your client, you should navigate to Mobile Services cockpit and find your MDK application that you want to link to this client.

  5. Click com.sap.mdk.certs > Security tab.

    Copy the Client ID, Redirect URL, OAuth Authorization, OAuth Token and paste to ClientId, RedirectUrl, AuthorizationEndPointUrl and TokenUrl parameters respectively.

    MDK
  6. AppId: App ID from Info tab.

    MDK
  7. ServerUrl: Server URL from APIs tab.

    MDK
  8. Add mdkclient://oauth2redirect in the AllowedDomains property.

    MDK

    If you are connecting to AliCloud accounts, you will also need to add your custom domains under the same AllowedDomains property. You can find more details in documentation.

  9. In the last section of BrandedSettings.json file, make these changes:

    Field Value
    DetailLabelViewText Branded client that can on-board using certificates for authentication
    SigninButtonText Start
    MDK
  1. In the MDKClient_SDK folder, you will find the template.mdkproject folder.

    MDK

    It is recommended that you copy this folder to another location so that you can to use it for future builds. Copy and paste it anywhere, and then rename template to MDKCertApp.mdkproject.

    MDK
  2. Next, you will need to update the MDKProject.json and BrandedSettings.json files as needed for your client. Go into the MDKCertApp.mdkproject folder.

    MDK
  3. Open the MDKProject.json file and update it as needed. This file has some build-time configurations such as the application name, version and bundle ID.

    MDK

    AppName: Provide a name for example: MDKCertApp. It is the name of the application on the home screen of the device and it is also the name of the folder where the client is created.

    BundleID: It should be a unique identifier for your application. This controls if the client can be installed side by side with other applications on the device. Two applications with the same Bundle ID cannot be installed at the same time on a device. In Android, it is known as application ID.

    URLScheme: Allows you to specify a custom URL scheme which opens the client. This value is provided in step 2 for Redirect URL.
    If the URL includes connection settings as URL parameters, these settings will override the ones used by the client. The default is mdkclient. This value needs to match the value provided in step 2 for the Redirect URL. This value also needs to be unique across applications on your device. If the value is not unique the wrong application may be referenced when redirecting.

  4. Open the BrandedSettings.json file and update the ConnectionSettings with the values for your MDK application in Mobile Services. You also need to add the "AllowCerts":true property into the ConnectionSettings block.

    MDK

    AllowCerts property allows MDK client to use the certificate. You can find more information about this property in help documentation. To access the certificate on the device during on-boarding if requested by the Identity provider (IdP).

    To find the correct URLs for your client, you should navigate to Mobile Services cockpit and find your MDK application that you want to link to this client.

  5. Click com.sap.mdk.certs > Security tab.

    Copy the Client ID, Redirect URL, OAuth Authorization & OAuth Token and paste to ClientId, RedirectUrl, AuthorizationEndPointUrl and TokenUrl parameters respectively.

    MDK
  6. AppId: App ID from Info tab.

    MDK
  7. ServerUrl: Server URL from APIs tab.

    MDK
  8. Add mdkclient://oauth2redirect in the AllowedDomains property.

    MDK

    If you are connecting to AliCloud accounts, you will also need to add your custom domains under the same AllowedDomains property. You can find more details in documentation.

  9. In the last section of BrandedSettings.json file, make these changes:

    Field Value
    DetailLabelViewText MDK Cert Auth App Demo
    SigninButtonText Start
    MDK
Which properties are part of ConnectionSettings in BrandedSettings.json file?
×
Step 4: Create the MDK Client

Make sure you are choosing the right development platform tab above.

  1. You can create a client by running ./create-client.command and providing the path to a valid .mdkproject directory.

    MDK

    You can run the create-client command from any directory. The resulting MDK client will be created in the directory where the create-client command is run from.

  2. You will be asked whether you would like to build for iOS or android or all?

    MDK

    All option was chosen in this tutorial as you will learn how to create the MDK client for iOS and Android.

    Once the create-client.command script executed successfully, you will see Application ready message in terminal console.

    You will also find your MDK Client app created under the MDKClient_SDK folder.

    MDK
  1. You can create a client by running create-client.cmd and providing the path to a valid .mdkproject directory.

    MDK

    You can run the create-client command from any directory. The resulting MDK client will be created in the directory where the create-client command is run from.

  2. Once the create-client.cmd script executed successfully, you will see Application ready message in terminal console.

    MDK

    You will also find your app created under the MDKClient_SDK folder.

    MDK

This name of this folder is based on the <App Name> provided in the MDKProject.json file.

Log on to answer question
Step 5: Run the MDK Client

Make sure you are choosing the right device platform tab above.

  1. In this step, you will run the app on an android device. Attach the device to your Mac or Windows machine and run tns device android command to print a list of attached devices.

    MDK

    Make sure Developer option and USB debugging option is enabled in android device.

  2. Copy the Device Identifier value for your device.

  3. In terminal or command line window, navigate to the app name folder MDKCertApp (in MDClient_SDK path) and use tns run android --device <device identifier> command to run the MDK client on android device.

    MDK

    Once, above command gets successfully executed, you will see new MDK client up and running in Android device.

  4. Tap AGREE on End User License Agreement.

    MDK
  5. In Welcome screen, you will notice that app name, detailed label text and signing button text have been updated as per changes done in step 3.4 & 3.6. Tap START to connect the MDK client to SAP Business Technology Platform (BTP).

    MDK
  6. As you enabled the certificate based authentication, MDK client detects a valid certificate installed on the device and connects successfully to the SAP BTP.

    MDK

    If the user certificate is not valid or not detectable, then you will see an SAP BTP login page.

  7. Choose a passcode with at least 8 characters for unlocking the app and tap NEXT.

    MDK
  8. Confirm the passcode and tap DONE.

    MDK
  9. Optionally, you can enable biometric authentication to get faster access to the app data.

    MDK

    Since you have not deployed any metadata yet you will not see the Update Now? dialog.

    MDK
  1. In this step, In this step, you will run the app on an iOS device. Attach the device to your Mac and run tns device ios command to print a list of attached devices.

    MDK
  2. Copy the Device Identifier value for your device.

  3. In terminal window, navigate to the app name folder MDKCertApp (in MDClient_SDK path) and use tns run ios --device <device identifier> command to run the MDK client on iOS device.

    MDK

    You can also run the app in Xcode. Open the project in Xcode with the command open platforms/ios/<app name>.xcworkspace, or open the workspace using the File -> Open... dialog in Xcode. Configure the application’s code signing settings, then run the application for the target device.

    Once, above command gets successfully executed, you will see new MDK client up and running in your device.

    MDK
  4. Tap Agree on End User License Agreement.

  5. In Welcome screen, you will notice that app name, detailed label text and signing button text have been updated as per changes done in step 3.4 & 3.6.

    MDK
  6. Tap Start to connect the MDK client to SAP Business Technology Platform (BTP). As you enabled the certificate based authentication, MDK client detects a valid certificate installed on the device and connects successfully to the SAP BTP.

    MDKMDK

    If the user certificate is not valid or not detectable, then you will see an SAP BTP login page.

  7. Choose a passcode with at least 8 characters for unlocking the app and tap Next.

    MDK
  8. Confirm the passcode and tap Done.

    MDK
  9. Optionally, you can enable biometric authentication to get faster access to the app data, tap Enable.

    MDK

    Since you have not deployed any metadata yet you will not see the Update Now? dialog.

    MDK

Congratulations, you have successfully built Your Mobile Development Kit Client that enables Certificate based authentication and you can continue with the remaining tutorials in this mission.

What is the default value for AppVersion in the MDKProject.json?
×
