Configure Authentication and Authorization on SAP BTP

Set up authentication and authorization on SAP BTP and deploy your secured application there.
You will learn
  • How to prepare your application for deployment with security enabled
  • How to test authorizations on the applications deployed to SAP BTP, Cloud Foundry

Before you deploy your authentication-enabled application you have to create an instance of service Authorization and Trust Management Service (XSUAA) and configure it, bind it to your application and provide it with the security descriptor that contains roles and scopes of your application. See section Protecting Your Application in the SAP BTP documentation for more details.

renejeglinskyRené JeglinskyAugust 10, 2022
Created by
iwonahahn
July 14, 2022
Contributors
iwonahahn
  • Step 1

    The XSUAA security descriptor that describes the roles for your application can be generated from your CDS service definitions. It is used to configure your XSUAA service instance.

    1. Open a new terminal window in SAP Business Application Studio from the menu using Terminal New Terminal and run the following commands:

      Shell/Bash
      Copy
      cd ~/projects/bookstore
      cds compile srv/ --to xsuaa > xs-security.json


      A new file xs-security.json will be created.

    2. Open the xs-security.json file in SAP Business Application Studio and update the file so it looks like that:

      JSON
      Copy
      {
        "xsappname": "bookstore",
        "tenant-mode": "dedicated",
        "scopes": [
          {
            "name": "$XSAPPNAME.Administrators",
            "description": "Administrators"
          }
        ],
        "attributes": [],
        "role-templates": [
          {
            "name": "Administrators",
            "description": "generated",
            "scope-references": [
              "$XSAPPNAME.Administrators"
            ],
            "attribute-references": []
          }
        ],
        "role-collections": [
          {
            "name": "BookStore_Administrators",
            "description": "BookStore Administrators",
            "role-template-references": ["$XSAPPNAME.Administrators"]
          }
        ]
      }


      You added the name of your application in the attribute xsappname and declared a role collection to which you can assign users later.

    3. Open the manifest.yml file and add the line bookstore-xsuaa under the services so that the result looks like this:

      YAML
      Copy
      ---
      applications:
      - name: bookstore
        path: srv/target/bookstore-exec.jar
        random-route: true
        services:
        - bookstore-hana
        - bookstore-xsuaa


    With this, your application uses this instance of Authorization and Trust Management Service (XSUAA) to manage authentication of users for your application. You will create the instance with that name in the next step.

  • Step 2
    1. You will now create the XSUAA service instance through the CF CLI. Execute the following command in a terminal:
      Shell/Bash
      Copy
      cd ~/projects/bookstore
      cf create-service xsuaa application bookstore-xsuaa -c xs-security.json


    In case you see an error like “Not logged in”. Execute cf login and provide your SAP BTP trial account credentials.

  • Step 3

    Now, you are ready to deploy the application with the security enabled.

    1. Build your CAP Java application by executing mvn clean install in the terminal.

    2. Deploy your application to SAP BTP using the command cf push.

    3. When the deployment is complete, open the URL to your application. It can be retrieved by executing the command cf app bookstore. You can find the URL under the entry routes in the output of the command.

  • Step 4

    Open your application in the browser. Using the links on the welcome page you can check that you can’t access the Orders entity or everything under the AdminService. You should see a 401 error in case you click on these.

    To test the secure endpoints of your application, you need a REST client like Postman that supports OAuth 2.0 authentication with type Authorization Code.

    Postman may behave differently, when you use SSO to log in to SAP BTP or to a custom identity provider. The following steps assume that you use a Trial account without SSO with the default SAP identity provider.

    1. To use the AdminService, you need to assign yourself to the role collection BookStore_Administrators that was defined in the xs-security.json file. To assign this role collection to your user you need to navigate to the Security Role Collections section of your SAP BTP subaccount. Select the BookStore_Administrators role collection and choose Edit. Enter your email address in the ID and E-Mail field and choose Save.

      role assignment to administrator
    2. Open a new terminal in SAP Business Application Studio. Run the command cf env bookstore to obtain the service binding credentials of your application. Look for the VCAP_SERVICES variable and the xsuaa node inside of its JSON structure.

      In case you see an error like “Not logged in”. Execute cf login and provide your SAP BTP trial account credentials.

    3. Under the credentials node, write down values of the following keys:

      • url
      • clientid
      • clientsecret

      These values are sensitive and should not be shared with anyone or committed to version control systems. They will change, when the binding to the instance Authorization and Trust Management Service changes.

      You will also need your application URL for the REST client. You can get it with the cf app bookstore command.

    4. Open Postman and create a new collection for your requests. On the collection level, select the Authorization tab and select OAuth 2.0 for the field Type. Make sure that Add auth data to is set to Request Headers.

    5. In the section Configure New Token, select Authorization Code for field Grant Type.

    6. In the field Callback URL, enter the URL of your bookstore application. Make sure that it is prefixed with https://.

    7. Enter the client ID and client secret in the fields Client ID and Client Secret.

    8. Fields Auth URL and Access Token URL should be filled with the URL obtained from the output of the cf env command. For the Auth URL, add /oauth/authorize to the end. For the Access Token URL, add /oauth/token to the end.

    9. Select Send client credentials in body for the field Client Authentication. The overall configuration should look like this:

      overall request setup

    10. Save your collection. You can now obtain an access token by clicking on the button Get New Access Token. You might have to enter the user and password you use to access SAP BTP cockpit. In the following step make sure to select the token, by clicking on Use Token.

    What credentials you use to access secured application deployed to SAP BTP?

  • Step 5

    You will now access your application using the token you have created earlier.

    1. Create a new request by right-clicking on the name of your collection and select Add request in the menu and give it a name.

    2. Enter the URL of your bookstore application and add the suffix /odata/v4/AdminService/Products.

    3. Select the tab Authorization and make sure the type is set to Inherit auth from parent.

    4. Send the request choosing Send.

    5. Your request will return all products that are available in the application.

    products in the application

    Done! You have learned how to deploy secured applications to SAP BTP, Cloud Foundry and issue requests to backend services deployed there.

    Can you store a Postman collection in the public GitHub repository, share it with your colleagues or store it in the cloud services?
